Harley Davidson 65948-04 Lithium Battery PV-3

Description

Provacell PV-3 Lithium Motorcycle Battery for Harley Davidson and other V-twin cruisers. Ideally suited to the Provacell Harley Battery Charger for optimum battery life and starting performance. Straight swap for Harley part number 65948-04 and the Harley 4aH lithium battery.

• A direct replacement for your existing Harley battery
• Significantly lighter with a higher cranking ability
• Longer life than a regular lead-acid battery
• Cheaper than a bog-standard Harley-Davidson battery
• Top quality: comes with our no quibble 2-year warranty

HARLEY LITHIUM BATTERY GUIDE

Here at Two Tyres we use and recommend these lightweight lithium Harley Davidson batteries, which weigh approximately 20% of your Harley’s standard lead-acid battery. This PV-3 / 65948-04 / VTB-3 fitment is the exact physical size of your outgoing battery, so it just slots right in. It is far lighter, weighing just 1.2kg, saving a massive 3.6kg compared to stock.

Lithium motorcycle batteries have just 10% of the self-discharge rate of a lead-acid battery, meaning you can leave it for months and the battery won’t die.

Our lithium-ion motorbike batteries are 100% safe to use. They are constructed using iron phosphate (LiFePO4) as the cathode material and use the lithium-polymer process in their manufacturing. This means that they can’t catch fire or explode in normal operation, which can happen with some cheap, low-quality batteries. The only thing you can do wrong with these batteries is overcharge them; if you connect them to a standard lead-acid battery charger, it will think it’s a dead battery and try and pump lots of amps into it, to revive it. This will kill the lithium battery.

Designed specifically for Harleys, with excellent vibration resistance, the PV-3 is built to last. The built-in processor ensures that all cells charge efficiently, prolonging battery life. Another plus point is that due to less internal resistance, they have a higher cranking ability than a lead-acid battery, which is useful when it comes to cranking over large v-twin engines.

Designed specifically for Harleys with excellent vibration resistance. A built-in processor ensures that all cells charge efficiently, prolonging battery life. Another plus point is that they have a higher cranking ability than a lead-acid battery, which is useful when it comes to cranking over large v-twin engines.

PV-3 BATTERY SPECIFICATION

Straight swap for a: Harley-Davidson Genuine Part Numbers: 65948-04

Model number: PV-3 / 65948-04 / 66000301

Type: Lithium, Maintenance free

Weight: 1.2kg (Stock Harley Davidson battery weight 4.8kg)

Length: 148mm

Width: 86mm (front to back)

Height: 144mm

Capacity: 6Ah

Manufacturer claimed CCA: 490A

Voltage: 12v

HARLEY-DAVIDSON EQUIVALENT

These batteries are a straight-swap for your stock H-D battery, just remove your old one and connect up your new one. No messing around. This model is comparable in dimensions and connections with these Harley and Yuasa part numbers:

• Harley-Davidson 65948-04

VTB-3 LITHIUM BATTERY FITMENT CHART

Harley Davidson XG 500 Street and ABS 2014 to 2017
Harley Davidson XG 750 Street and ABS 2014 to 2017
Harley Davidson XL 883 Sportster 2004 to 2009
Harley Davidson XL 883 C Sportster Custom 2005 to 2010
Harley Davidson XL 883 N Sportster Iron and ABS 2009 to 2017
Harley Davidson XL 883 L Sportster Low 2005 to 2010
Harley Davidson XL 883 R Sportster Roadster and ABS 2007 to 2015
Harley Davidson XL 883 R Sportster Roadster Race Replica 2006
Harley Davidson XL 883 L Sportster Super Low and ABS 2011 to 2017
Harley Davidson XL 1200 C Sportster Custom and ABS 2004 to 2017
Harley Davidson XL 1200 CA Sportster Custom Limited Edition A and ABS 2013 to 2016
Harley Davidson XL 1200 CB Sportster Custom Limited Edition B and ABS 2013 to 2017
Harley Davidson XL 1200 X Sportster Forty Eight and ABS 2010 to 2017
Harley Davidson XL 1200 L Sportster Low 2007 to 2009
Harley Davidson XL 1200 N Sportster Nightster 2008 to 2012
Harley Davidson XL 1200 R Sportster Roadster 2004 to 2008
Harley Davidson XL 1200 CX Sportster Roadster ABS 2017
Harley Davidson XL 1200 V Sportster Seventy-Two and ABS 2013 to 2016
Harley Davidson XL 1200 T Sportster Superlow ABS 2014 to 2017
Harley Davidson XL 53 883 C Sportster Custom 2004
Harley Davidson XL-ANV 1200 C Sportster Custom Anniversary 2013
Harley Davidson XR 1200 2008 to 2010
Harley Davidson XR 1200 X 2010 to 2012

LITHIUM BATTERY BENEFITS

• Very low self-discharge (approximately 3-5% per month)
• Rapid charging possible (up to 90% in under 20 minutes)
• Direct swap for the stock battery in 95% of sizes and where smaller, adhesive foam padding is provided
• Great cost to weight-saving ratio
• LiFePO4 construction eliminates fire risk

Note: you can not use a lead-acid battery charger on these Lithium batteries as you will overcharge and damage them. We sell a motorcycle battery charger that charges both lithium and lead-acid batteries.

Click the Read More link below to see the Harley-Davidson model fitments for this battery.
